Maximum Power Capacity |
300 HP (230 kW) |
Lower Unit Design |
Low-Drag Hydrodynamic Torpedo |
Maximum Propeller Diameter |
15″ |
Water Inlet Location |
Strut |
Clutch Type |
Compact Dog Clutch with F-N-R |
Available Gear Ratios |
1.47, 1.62, 1.81, 2.00, 2.40:1 |
Counter-Rotation |
Optional, Except 2.40:1 Ratio |
Upper Unit Gear Set |
Precision Shimmed, Spiral Bevel Gear |
Lower Unit Gear Set |
Precision Shimmed, Spiral Bevel Gear |
Propshaft Material |
Heat-Treated Stainless Steel |
Standard Exhaust Outlet |
Through Propeller |
Propeller Hub Type |
Flo-Torq II Hub |
Recommended Lubricant |
Mercury High-Performance Gear Lube |
Monitoring System |
Engine-Mounted Lube Monitor w/Audio Warning or Engine Guardian® |
Corrosion Warranty |
3-Year, Limited |
Housing Construction |
Corrosion Resistant XK 360 Aluminum Low-Copper Alloy |
Corrosion Protection |
Tri-Paint, Anodes & MerCathode® as a Kit |
Anode Type |
Ultra-Pure Aluminum Anodes or Magnesium Anode Kit |
Speedometer Pick-up |
Integrated Into Lower Housing |
Steering System |
Single Cylinder Power Steering with Anti-Feedback |
Steering Range |
56° Range Stop to Stop |
U-Joint Type |
Permalube® Virtually Maintenance-Free |
Power Trim System |
Twin-Cylinder Hydraulic Featuring Power Trim XD® Kick-up Return |
Typical Trim Range |
5° to 15° |
Trim Limit Switch |
Standard – Adjustable |
Trailer Limit |
53° |
Trim Hinge Pin Design |
Permanently Lubricated – No Maintenance Required |
Hydraulic Trim Lines |
Stainless Steel Braided Armor |
Drive Coupler |
Greaseable From Inside Boat |
Drive Weight |
85 lbs. (38 kg) |
